Step 1
Upload topographical scan data through the easy-to-use interface
Step 2
Fully customize your PV plant layout & system without repetitive design tasks.
Step 3
Create precise construction-ready plans and drawings to eliminate installation problems on-site
Creates Value
work in 2D terrain Automated work in
3D terrain with PVCase
AUTOMATION
Saves engineers up to 30x time
As per our experience, preparing a regular 21 MW solar site takes an engineer around 2 weeks and includes over 40 hours of manual work with AutoCAD. PVcase reduces this to around 1.3 hours, so the design can be finished just in a day or two.
3D TERRAIN BASED ENGINEERING
Results in up to 10% better precision for cabling and yield
Creating a solar park design in 2D environment and then actually building it in 3D terrain creates all sorts of miscalculations. PVcase makes actually designing solar parks in 3D environment possible, bringing the unprecedented precision.
Features
UNPRECEDENTED PRECISION
3D terrain based PV layouts
Get realistic ground-mount PV layouts quickly, with imported terrain details to optimize frame placement.
ELIMINATES REPETITIVE WORK
Fully customizable electrical design
Automate the stringing and placement of electrical equipment, using advanced algorithms that comply with industry standards.
EXTRA ACCURACY
Automated topographical 3D cabling
Get precise cable lengths that trail based on the terrain, increasing cable sizing & loss calculation precision.
SAVES TIME
Export 3D shading scenes to PVSyst & other 3D rendering software
Transfer your whole PV plant with ease. All 3D elements are exported so you can get very precise yield reports or create impressive tender visuals.
...and many more to save time on more precise designs
Created by Solar Engineers for Solar Engineers
PVcase has been designed and developed as a collaboration between solar PV engineers from DETRA and expert software engineers. DETRA has been in the solar engineering business since 2009 designed 9.4 GW of solar energy systems in 48 countries around the globe.
